Descriptions

Conforms to API 526 Full Nozzle Design Integral Cast Flanges Metal Seat with optional O-ring Balanced Bellows option Open Bonnet and Lever Assemblies option Adjustable Blowdown 2600L – Multiple Service Single Trim Design option

Specifications Product

Size 1” x 2” to 20” x 24” Orifice Areas D (0.15in2) to Z (176.7 in2) Set Pressure Ranges 15 to 6000 psig (1.0 to 413 barg) Temperature Ranges -320 to 1500°F (-195 to 815°C) Flange Classes: 150# – 2500# Suitable for Air, Gas, Vapor, Steam & Liquid Service Materials of Construction: Carbon Steel Stainless Steel, Low/High-Temperature Alloy Steels, Monel, Hastelloy C, Duplex, NACE Compliant Materials Certifications ASME/NB Section VIII and III for Air, Steam and Water CSA B51 (Canada CRN) ISO 9001- 2008 PED 97/23/EC (European Pressure Equipment Directive) ATEX 94/9/EC (European Potentially Explosive Atmospheres) CSQL (China) GOST-R (Russian) US Coast Guard Nuclear – 10 CRF 50 Appendix B, NCA-4000, NQA-1 N285.0 First Point Assessment Limited

Untuk pemesanan produk silahkan klik tombol "ORDER NOW" dan isi data pesan, atau bisa langsung menghubungi kami by Whatsapp / Email.
